CloudWatch Logs

Last Updated: September 13, 2026 Checked examples: AWS provider 6.64.0; optional CloudWatch Observability Helm chart 6.6.0; manual AWS for Fluent Bit 3.4.15/Fluent Bit 5.0.9. Local configuration, SDK and synthetic-payload checks only. No AWS resources, log delivery, Insights queries or alarms were executed.

Amazon CloudWatch Logs manages log ingestion, storage and analysis. You still configure producers, identity, networking, retention, quotas and downstream consumers. EKS control-plane logs, workload logs and EKS Auto Mode managed-component logs are separate collection paths.

Table of Contents

1. Overview
2. EKS Control Plane Logging
3. Container Insights
4. FluentBit Integration
5. CloudWatch Logs Insights
6. Subscription Filters
7. Cost Optimization

Overview

Features and Log Classes

Area	What to check
Managed service	No search cluster to operate, but collectors and delivery integrations still need an owner
Capacity	Event-size, API, subscription and destination quotas apply; ingestion is not unlimited
Security	IAM, encryption, data protection and private connectivity have separate configuration
Timeliness	Delivery and alerting are asynchronous; retries and duplicate or missing deliveries must be considered
Standard class	Supports the metric filters and subscriptions used in this chapter
Infrequent Access	Lower ingestion pricing and a different feature set; no subscription filters, metric filters or EMF
Delivery class	A separate option for Lambda logs delivered to S3/Firehose; fixed two-day CloudWatch retention and no Logs Insights queries

A log group's class cannot be changed after creation. Infrequent Access currently supports features including S3 export, Logs Insights and data protection, so older blanket statements that it supports none of these are incorrect. Check the current feature table before changing the collection design.

Key Concepts

Subscription filters do not take an S3 bucket ARN as their destination. Continuous S3 delivery through Firehose and an asynchronous S3 export task are different paths. CloudWatch Logs batches also cannot be delivered through Firehose's OpenSearch destination; use the documented CloudWatch-to-OpenSearch integration instead. Direct application records sent to Firehose are a different input contract.

Term	Meaning
Log group	Common retention, access and configuration boundary; for example /aws/eks/example-eks/cluster
Log stream	A sequence of log events within a group
Log event	Timestamp and message, subject to service limits
Retention	A supported discrete retention period, or no expiry if retention is not set

EKS Control Plane Logging

Log Types

The five types are api, audit, authenticator, controllerManager and scheduler. They cover API-server diagnostics, audit events, IAM authentication, controller-manager diagnostics and scheduling respectively. Worker-node and application logs are separate.

Control-plane logging is disabled by default. Select types according to your diagnostic, security and retention requirements; the API does not mandate the earlier table's “required” choices. Delivery normally takes minutes and is best effort. Enabling logging does not recover already rotated historical logs.

Enable and Observe the Update

For an existing cluster, save the following as control-plane-logging.json:

{
  "clusterLogging": [
    {
      "types": [
        "api",
        "audit",
        "authenticator",
        "controllerManager",
        "scheduler"
      ],
      "enabled": true
    }
  ]
}

DOCS_CLUSTER=example-eks
DOCS_REGION=ap-northeast-2

aws eks describe-cluster --name "$DOCS_CLUSTER" --region "$DOCS_REGION" \
  --query 'cluster.{version:version,logging:logging}'

UPDATE_ID=$(aws eks update-cluster-config \
  --name "$DOCS_CLUSTER" --region "$DOCS_REGION" \
  --logging file://control-plane-logging.json --query update.id --output text)

aws eks describe-update --name "$DOCS_CLUSTER" --region "$DOCS_REGION" \
  --update-id "$UPDATE_ID" --query 'update.{status:status,errors:errors}'

The update must reach Successful; request acceptance alone is insufficient. Logging updates can require up to five free IP addresses per cluster subnet. To disable a type, explicitly review that change rather than copying a second example that silently turns off existing logs.

Terraform Ownership and Retention

For Terraform-managed clusters, change enabled_cluster_log_types in the existing cluster resource's owning configuration. Do not create another aws_eks_cluster resource just to enable logs, and do not copy the obsolete Kubernetes 1.29 creation example.

The following separate file manages the log groups and the manual collector's policy:

terraform {
  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = "6.64.0"
    }
  }
}

variable "region" {
  type    = string
  default = "ap-northeast-2"
}

variable "account_id" {
  type = string
  validation {
    condition     = can(regex("^[0-9]{12}$", var.account_id))
    error_message = "Use the owning account ID."
  }
}

variable "cluster_name" {
  type    = string
  default = "example-eks"
}

provider "aws" {
  region = var.region
}

resource "aws_cloudwatch_log_group" "application" {
  name              = "/aws/containerinsights/${var.cluster_name}/application"
  log_group_class   = "STANDARD"
  retention_in_days = 30

  lifecycle {
    prevent_destroy = true
  }
}

resource "aws_cloudwatch_log_group" "control_plane" {
  name              = "/aws/eks/${var.cluster_name}/cluster"
  log_group_class   = "STANDARD"
  retention_in_days = 30

  lifecycle {
    prevent_destroy = true
  }
}

resource "aws_iam_policy" "collector" {
  name_prefix = "fluent-bit-cloudwatch-"
  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [{
      Effect   = "Allow"
      Action   = ["logs:CreateLogStream", "logs:PutLogEvents"]
      Resource = "${aws_cloudwatch_log_group.application.arn}:*"
    }]
  })
}

output "collector_policy_arn" {
  value = aws_iam_policy.collector.arn
}

If a group already exists, reuse its owner or import it into the intended state before applying. For example, the control-plane group uses the import ID /aws/eks/example-eks/cluster. Do not declare the same group again as an “audit” group: all five control-plane types share this group and its retention.

The 30-day values are examples, not legal requirements. prevent_destroy blocks Terraform destruction, but does not prevent retention reductions or deletion outside Terraform. CloudWatch encrypts stored log data; a customer-managed KMS key requires its own key policy and operational planning.

Log Group Structure

/aws/eks/example-eks/cluster
  kube-apiserver-...          API server
  kube-apiserver-audit-...    Audit
  authenticator-...          IAM authentication
  kube-controller-manager-... Controller manager
  kube-scheduler-...         Scheduler

Stream suffixes rotate. The example /aws/eks/cluster/logs in the old figure was not the actual control-plane group naming convention.

Container Insights

Installation Choices

Use the current Amazon CloudWatch Observability EKS add-on or its amazon-cloudwatch-observability Helm chart. The former ADOT exporter chart and an unsubstituted quickstart URL are not equivalent installations.

For an add-on, discover versions compatible with the actual cluster, inspect the selected configuration schema and configure the documented IAM association. A chart version is not an EKS add-on version string.

K8S_VERSION=$(aws eks describe-cluster --name "$DOCS_CLUSTER" \
  --region "$DOCS_REGION" --query cluster.version --output text)
aws eks describe-addon-versions \
  --addon-name amazon-cloudwatch-observability \
  --kubernetes-version "$K8S_VERSION" --region "$DOCS_REGION"

The optional Helm example uses the following cloudwatch-values.yaml. It selects the traditional Container Insights path and container logs; Application Signals and the separate OTel Container Insights pipeline are disabled here.

clusterName: example-eks
region: ap-northeast-2
containerInsights:
  enabled: true
containerLogs:
  enabled: true
applicationSignals:
  enabled: false
otelContainerInsights:
  enabled: false
  logs:
    enabled: false

helm repo add aws-observability https://aws-observability.github.io/helm-charts
helm repo update aws-observability
helm upgrade --install cloudwatch-observability \
  aws-observability/amazon-cloudwatch-observability \
  --version 6.6.0 --namespace amazon-cloudwatch --create-namespace \
  --values cloudwatch-values.yaml

Set IAM permissions before installation. In this chart, the Fluent Bit DaemonSets use the cloudwatch-agent service account; its name and namespace must match the selected Pod Identity association. Follow the official association/role-trust requirements. An IRSA role for a differently named service account will not authorize a manually created fluent-bit Pod. Do not install this chart over an EKS-managed add-on or run duplicate collectors on the same logs.

Collected Logs and Platforms

Typical group suffix	Content and limits
application	Container stdout/stderr under /aws/containerinsights/CLUSTER/application
dataplane	Configured kubelet/runtime/VPC CNI/kube-proxy sources; actual components vary by platform
host	Configured Linux files/journals or Windows event logs; not every OS has /var/log/messages, /var/log/secure or /var/log/dmesg
performance	Performance events, often EMF; not interchangeable with application log messages

The supported add-on/chart has Linux and Windows paths, but Application Signals is not supported for EKS Windows. Fargate uses its platform log router, not this manual DaemonSet. Verify Hybrid Nodes and Auto Mode separately; do not assume traditional EC2 host paths exist everywhere.

EKS Auto Mode's AWS-managed Karpenter, EBS CSI, load-balancer-controller and IPAM logs use a separate vended log delivery setup. Its log types are AUTO_MODE_COMPUTE_LOGS, AUTO_MODE_BLOCK_STORAGE_LOGS, AUTO_MODE_LOAD_BALANCING_LOGS and AUTO_MODE_IPAM_LOGS. The documented PutDeliverySource → PutDeliveryDestination → CreateDelivery flow can target a log group, S3 or Firehose. That is distinct from PutSubscriptionFilter and from enabling the five control-plane log types.

FluentBit Integration

Manual Application-Log Collector

This is an alternative application-log-only profile for eligible Linux EC2 nodes. It does not install the complete Container Insights metric pipeline or promise universal host/dataplane collection.

Create or reuse the application group first. The collector policy above allows stream creation and event writes to that group; it deliberately does not create groups or change retention. The manual profile therefore does not need cloudwatch:PutMetricData, s3:PutObject, or blanket logs:* permissions.

Prepare an approved IRSA role whose OIDC trust matches system:serviceaccount:logging:fluent-bit-cloudwatch and audience sts.amazonaws.com, and attach the generated policy. An eksctl --role-only workflow can create the role while the manifest owns the ServiceAccount. Replace the role ARN, cluster name and Region consistently.

apiVersion: v1
kind: Namespace
metadata:
  name: logging
---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: fluent-bit-cloudwatch
  namespace: logging
  annotations:
    eks.amazonaws.com/role-arn: arn:aws:iam::123456789012:role/FluentBitCloudWatchLogsRole
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: fluent-bit-cloudwatch-metadata
rules:
- apiGroups:
  - ''
  resources:
  - namespaces
  - pods
  verbs:
  - get
  - list
  - watch
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: fluent-bit-cloudwatch-metadata
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: fluent-bit-cloudwatch-metadata
subjects:
- kind: ServiceAccount
  name: fluent-bit-cloudwatch
  namespace: logging
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: fluent-bit-cloudwatch-config
  namespace: logging
data:
  fluent-bit.conf: |
    [SERVICE]
        Flush         5
        Grace         30
        Log_Level     info
        HTTP_Server   Off
        storage.path  /buffers/storage

    [INPUT]
        Name              tail
        Tag               application.*
        Path              /var/log/containers/*.log
        Exclude_Path      /var/log/containers/fluent-bit-cloudwatch-*_logging_fluent-bit-*.log
        multiline.parser  docker, cri
        DB                /buffers/tail.db
        Mem_Buf_Limit     50MB
        Skip_Long_Lines   On
        Read_from_Head    Off
        storage.type      filesystem

    [FILTER]
        Name                kubernetes
        Match               application.*
        Kube_Tag_Prefix     application.var.log.containers.
        Use_Kubelet         Off
        Merge_Log           On
        Merge_Log_Key       log_processed
        Keep_Log            On
        Labels              Off
        Annotations         Off
        K8S-Logging.Parser  Off
        K8S-Logging.Exclude Off

    [OUTPUT]
        Name                     cloudwatch_logs
        Match                    application.*
        region                   ap-northeast-2
        log_group_name           /aws/containerinsights/example-eks/application
        log_stream_prefix        ${HOST_NAME}-
        auto_create_group        false
        Retry_Limit              5
        storage.total_limit_size 1G
---
apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: fluent-bit-cloudwatch
  namespace: logging
spec:
  selector:
    matchLabels:
      app: fluent-bit-cloudwatch
  template:
    metadata:
      labels:
        app: fluent-bit-cloudwatch
    spec:
      serviceAccountName: fluent-bit-cloudwatch
      nodeSelector:
        kubernetes.io/os: linux
      tolerations:
      - operator: Exists
        effect: NoSchedule
      containers:
      - name: fluent-bit
        image: public.ecr.aws/aws-observability/aws-for-fluent-bit:3.4.15@sha256:88e1b56cedb230486afeca6eeb26c5f6bd59c48879d0054d1674d5a58838c607
        args:
        - -c
        - /fluent-bit/custom/fluent-bit.conf
        securityContext:
          runAsUser: 0
          allowPrivilegeEscalation: false
          readOnlyRootFilesystem: true
          capabilities:
            drop:
            - ALL
          seccompProfile:
            type: RuntimeDefault
        resources:
          requests:
            cpu: 100m
            memory: 128Mi
          limits:
            memory: 512Mi
        volumeMounts:
        - name: logs
          mountPath: /var/log
          readOnly: true
        - name: buffers
          mountPath: /buffers
        - name: config
          mountPath: /fluent-bit/custom
          readOnly: true
        - name: tmp
          mountPath: /tmp
        command:
        - /fluent-bit/bin/fluent-bit
        env:
        - name: HOST_NAME
          valueFrom:
            fieldRef:
              fieldPath: spec.nodeName
      volumes:
      - name: logs
        hostPath:
          path: /var/log
          type: Directory
      - name: buffers
        hostPath:
          path: /var/lib/fluent-bit-cloudwatch
          type: DirectoryOrCreate
      - name: config
        configMap:
          name: fluent-bit-cloudwatch-config
      - name: tmp
        emptyDir: {}
      terminationGracePeriodSeconds: 45

The native plugin is cloudwatch_logs; the older Go plugin is named cloudwatch. The image's default command is an entrypoint script, so the manual manifest explicitly starts the native Fluent Bit binary with its configuration.

The Tail DB and filesystem buffer are writable and separate from the read-only log mount. Grace is 30 seconds and the Pod termination grace is 45 seconds, but that does not guarantee all buffered data is delivered. Node loss, full disks, long lines, finite retries and restart offsets can still lose logs. Read_from_Head Off affects previously unseen files; persistent offsets still matter.

The profile uses API-server metadata lookup rather than host-network kubelet access. Application annotations cannot change parsing or exclude logs. Do not set the reserved extra_user_agent: container-insights value in a custom collector to imply it is the managed installation.

Record Contract and Host Sources

An illustrative enriched event sent to CloudWatch is:

{"log":"{\"level\":\"error\",\"message\":\"upstream request failed\",\"error_type\":\"upstream_timeout\",\"http\":{\"response_time_ms\":1250,\"status_code\":503}}","stream":"stderr","kubernetes":{"namespace_name":"production","pod_name":"api-example","container_name":"api"},"log_processed":{"level":"error","message":"upstream request failed","error_type":"upstream_timeout","http":{"response_time_ms":1250,"status_code":503}}}

Application fields are under log_processed, while trusted Kubernetes metadata is under kubernetes. The raw log string duplicates application data; redact prohibited fields before collection. The query, subscription and metric-filter examples below use this exact JSON envelope and lowercase level: error.

If you need Linux journal collection, verify whether persistent journals exist at /var/log/journal or volatile journals at /run/log/journal. Configure a systemd input, appropriate unit filters, read-only mounts, separate writable DB, output group and IAM permissions. Do not blindly mount Docker's old /var/lib/docker/containers path or require nonexistent text files on containerd/Bottlerocket/AL2023 nodes. These platform-specific host configurations are not deployed by the manual profile.

CloudWatch Logs Insights

These examples use Logs Insights QL, not SQL. Select the intended log group and a bounded time range. Local review checked published syntax/contracts; no managed query service was called.

Basic Query Syntax

fields @timestamp, @message
| filter @message like /(?i)error/
| sort @timestamp desc
| limit 100

Case-insensitive regex uses /(?i)error/, not JavaScript's /error/i suffix. Text matching can match words that are not an application's structured error level.

For the collector's JSON envelope:

fields jsonParse(@message) as record
| filter record.log_processed.level = "error"
| fields @timestamp, record.log_processed.message as message
| sort @timestamp desc
| limit 100

For an actual text field containing user_id=12345:

fields @timestamp, @message
| parse @message /user_id=(?<user_id>\d+)/
| filter user_id = "12345"
| limit 100

Do not rely on a glob that assumes arbitrary JSON key order and whitespace. jsonParse and explicit nested fields make the expected record structure clear.

EKS Log Query Examples

API-server diagnostics exclude the overlapping audit stream prefix:

fields @timestamp, @logStream, @message
| filter @logStream like /^kube-apiserver-/
| filter @logStream not like /^kube-apiserver-audit-/
| filter @message like /(?i)error/
| sort @timestamp desc
| limit 50

Audit activity for a specific Kubernetes username:

fields jsonParse(@message) as audit
| filter @logStream like /^kube-apiserver-audit-/
| filter audit.user.username = "example-user"
| fields @timestamp, audit.verb as verb, audit.objectRef as objectRef
| sort @timestamp desc
| limit 100

Authenticator diagnostics:

fields @timestamp, @message
| filter @logStream like /^authenticator-/
| filter @message like /(?i)(AccessDenied|Forbidden|unauthorized)/
| sort @timestamp desc
| limit 100

Pod create/delete audit events:

fields jsonParse(@message) as audit
| filter @logStream like /^kube-apiserver-audit-/
| filter audit.verb in ["create", "delete"]
| filter audit.objectRef.resource = "pods"
| fields @timestamp, audit.verb as verb, audit.objectRef.name as pod
| sort @timestamp desc
| limit 100

These are diagnostic searches, not proof that audit captures every action or that text matches establish the root cause.

Application Log Queries

Errors by namespace:

fields jsonParse(@message) as record
| filter record.log_processed.level = "error"
| stats count(*) as error_count by record.kubernetes.namespace_name as namespace
| sort error_count desc

Slow responses using the declared numeric millisecond field:

fields jsonParse(@message) as record
| filter record.kubernetes.container_name = "api"
| filter record.log_processed.http.response_time_ms > 1000
| fields @timestamp, record.log_processed.http.response_time_ms as response_time_ms
| sort response_time_ms desc
| limit 100

Hourly event counts:

stats count(*) as log_count by bin(1h) as bucket
| sort bucket asc

After stats, sort the defined bucket alias; the original per-event @timestamp is no longer a grouping output.

Top error categories:

fields jsonParse(@message) as record
| filter record.log_processed.level = "error"
| stats count(*) as error_count by record.log_processed.error_type as error_type
| sort error_count desc
| limit 10

A bounded category is usually more interpretable than grouping by every unique full message. Do not turn request IDs or arbitrary messages into unbounded metric dimensions.

Advanced Queries

fields jsonParse(@message) as record
| filter ispresent(record.log_processed.http.response_time_ms)
| stats pct(record.log_processed.http.response_time_ms, 50) as p50_ms,
        pct(record.log_processed.http.response_time_ms, 90) as p90_ms,
        pct(record.log_processed.http.response_time_ms, 99) as p99_ms
  by bin(5m) as bucket
| sort bucket asc

The QL aggregate is pct, not percentile. The producer must emit numeric milliseconds; the old nginx examples had mismatched wildcard counts and invented field positions.

fields @timestamp, @message, @logStream
| filter @message like /Back-off restarting failed container/
| stats count(*) as backoff_log_events by @logStream
| sort backoff_log_events desc

This counts matching log events, not container restarts. A kubelet event/message may be absent, repeated or aggregated. Use an appropriate Kubernetes restart metric when you need an actual restart count.

SOURCE is supported in CLI/API queries, not the console query editor:

SOURCE logGroups(accountIdentifier:['111122223333'], namePrefix:['/aws/containerinsights/prod-', '/aws/containerinsights/stage-'])
| fields @timestamp, @message, @logStream
| filter @message like /(?i)error/
| sort @timestamp desc
| limit 100

accountIdentifier is singular. Cross-account queries require an approved monitoring/source-account setup and permissions; mentioning a second account or group does not create that access. Omitting account/prefix selection can greatly widen a query.

Subscription Filters

Subscription filters forward new matching events asynchronously. Delivery is at least once; duplicates may occur. Retryable destination failures can be retried for up to 24 hours; non-retryable errors and sustained failures can lose deliveries. Monitor quotas, DeliveryErrors and DeliveryThrottling. Subscriptions do not backfill all historical logs.

The direct Lambda, Kinesis and Firehose destinations in these examples belong to the same account as the log group. Cross-account delivery uses a supported logical destination and its destination policy; an arbitrary cross-account Lambda ARN is not a substitute.

Archive to S3 through Firehose

This optional file uses the group above, an existing private S3 bucket, and an approved Firehose delivery role:

variable "firehose_delivery_role_arn" {
  type = string
}

variable "archive_bucket_arn" {
  type = string
}

resource "aws_cloudwatch_log_group" "firehose" {
  name              = "/aws/kinesisfirehose/cloudwatch-archive"
  retention_in_days = 30
}

resource "aws_cloudwatch_log_stream" "firehose" {
  name           = "S3Delivery"
  log_group_name = aws_cloudwatch_log_group.firehose.name
}

resource "aws_kinesis_firehose_delivery_stream" "archive" {
  name        = "cloudwatch-archive"
  destination = "extended_s3"

  extended_s3_configuration {
    role_arn            = var.firehose_delivery_role_arn
    bucket_arn          = var.archive_bucket_arn
    prefix              = "cloudwatch/year=!{timestamp:yyyy}/month=!{timestamp:MM}/day=!{timestamp:dd}/"
    error_output_prefix = "errors/!{firehose:error-output-type}/year=!{timestamp:yyyy}/"
    buffering_size      = 64
    buffering_interval  = 300
    compression_format  = "UNCOMPRESSED"

    cloudwatch_logging_options {
      enabled         = true
      log_group_name  = aws_cloudwatch_log_group.firehose.name
      log_stream_name = aws_cloudwatch_log_stream.firehose.name
    }
  }
}

resource "aws_iam_role" "logs_to_firehose" {
  name_prefix = "cloudwatch-to-firehose-"
  assume_role_policy = jsonencode({
    Version = "2012-10-17"
    Statement = [{
      Effect    = "Allow"
      Principal = { Service = "logs.amazonaws.com" }
      Action    = "sts:AssumeRole"
      Condition = {
        StringEquals = { "aws:SourceAccount" = var.account_id }
        ArnLike      = { "aws:SourceArn" = "arn:aws:logs:${var.region}:${var.account_id}:*" }
      }
    }]
  })
}

resource "aws_iam_role_policy" "logs_to_firehose" {
  role = aws_iam_role.logs_to_firehose.id
  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [{
      Effect   = "Allow"
      Action   = ["firehose:PutRecord", "firehose:PutRecordBatch"]
      Resource = aws_kinesis_firehose_delivery_stream.archive.arn
    }]
  })
}

resource "aws_cloudwatch_log_subscription_filter" "archive" {
  name            = "application-archive"
  log_group_name  = aws_cloudwatch_log_group.application.name
  filter_pattern  = ""
  destination_arn = aws_kinesis_firehose_delivery_stream.archive.arn
  role_arn        = aws_iam_role.logs_to_firehose.arn

  depends_on = [aws_iam_role_policy.logs_to_firehose]
}

The delivery role needs its reviewed Firehose trust, bucket/prefix access, optional KMS permissions and destination-log permissions. The CloudWatch-to-Firehose role is separate, and the deployer needs scoped iam:PassRole. Avoid subscribing delivery-error logs back into their own pipeline.

CloudWatch subscription records are already gzip-compressed. UNCOMPRESSED here disables additional Firehose compression; it does not turn the incoming payload into plain text or remove the CloudWatch envelope. Consumers must handle the actual archived record format.

For decompressed output, configure Firehose's documented decompression feature deliberately. Optional message extraction removes owner, logGroup, logStream and other envelope metadata. Do not mix vended-log input with a stream configured for CloudWatch-subscription decompression, and do not assume these settings make the unsupported CloudWatch→Firehose→OpenSearch path valid.

Process with Lambda

The example processes the structured envelope above, ignores control messages, and sends an error summary rather than raw log text. Save it as log_processor.py:

import base64
import gzip
import hashlib
import io
import json
import os

import boto3

# Example processing limit, not an AWS service quota.
MAX_UNCOMPRESSED_BYTES = 8 * 1024 * 1024


def summarize(event):
    compressed = base64.b64decode(event["awslogs"]["data"], validate=True)
    with gzip.GzipFile(fileobj=io.BytesIO(compressed)) as stream:
        payload = stream.read(MAX_UNCOMPRESSED_BYTES + 1)
    if len(payload) > MAX_UNCOMPRESSED_BYTES:
        raise ValueError("Batch exceeds this example's processing limit")
    batch = json.loads(payload)
    if batch.get("messageType") == "CONTROL_MESSAGE":
        return None
    if batch.get("messageType") != "DATA_MESSAGE":
        raise ValueError("Unsupported subscription message type")

    errors = []
    unparsed = 0
    for item in batch["logEvents"]:
        try:
            record = json.loads(item["message"])
            application = record["log_processed"]
            if not isinstance(application, dict):
                raise ValueError("Expected an application object")
        except (ValueError, KeyError, TypeError):
            unparsed += 1
            continue
        if application.get("level") == "error":
            errors.append(item)
    if not errors:
        return None

    # Raw messages are intentionally excluded from the notification.
    event_keys = [
        hashlib.sha256(
            json.dumps([batch["owner"], batch["logGroup"], batch["logStream"], item["id"]],
                       ensure_ascii=True).encode("utf-8")
        ).hexdigest()
        for item in errors[:20]
    ]
    return {
        "errorCount": len(errors),
        "unparsedRecords": unparsed,
        "sampleEventKeys": event_keys,
    }


def lambda_handler(event, context):
    summary = summarize(event)
    if summary is None:
        return {"notified": False}
    topic_arn = os.environ["ALERT_TOPIC_ARN"]  # Non-secret destination identifier.
    message = json.dumps(summary, ensure_ascii=True)
    if len(message.encode("utf-8")) > 262144:
        raise ValueError("SNS message is too large")
    boto3.client("sns").publish(
        TopicArn=topic_arn,
        Subject="CloudWatch Logs error batch",
        Message=message,
    )
    return {"notified": True, "errorCount": summary["errorCount"]}

ALERT_TOPIC_ARN is a non-secret destination identifier for an approved same-Region topic. The Lambda execution role needs scoped sns:Publish and its own log permissions, plus applicable KMS permissions. Its logging group must not recursively feed the same subscription.

The 8MiB processing limit is a chosen example bound, not an AWS quota. Invalid envelopes raise errors; records outside the expected application schema are not treated as structured errors. Monitor parsing failures, configure failure handling, and test replay before deployment. SNS non-SMS messages are limited by UTF-8 bytes, not a 1,000-character rule; the fixed subject also stays below the subject limit.

Event keys aid investigation; they are not persistent deduplication. Repeated invocations can send repeated notifications. A production consumer needs explicit idempotency and failure-destination decisions.

Metric Filters and Alarms

The following optional file connects an already deployed, unqualified Lambda function ARN and creates a count metric/alarm. It uses the same JSON field as the collector and queries:

variable "processor_function_arn" {
  type = string
}

variable "alerts_topic_arn" {
  type = string
}

resource "aws_lambda_permission" "cloudwatch" {
  statement_id   = "AllowOwnedCloudWatchLogGroup"
  action         = "lambda:InvokeFunction"
  function_name  = var.processor_function_arn
  principal      = "logs.${var.region}.amazonaws.com"
  source_arn     = "${aws_cloudwatch_log_group.application.arn}:*"
  source_account = var.account_id
}

resource "aws_cloudwatch_log_subscription_filter" "processor" {
  name            = "structured-errors"
  log_group_name  = aws_cloudwatch_log_group.application.name
  filter_pattern  = "{ $.log_processed.level = \"error\" }"
  destination_arn = var.processor_function_arn

  depends_on = [aws_lambda_permission.cloudwatch]
}

resource "aws_cloudwatch_log_metric_filter" "errors" {
  name           = "StructuredErrorCount"
  log_group_name = aws_cloudwatch_log_group.application.name
  pattern        = "{ $.log_processed.level = \"error\" }"

  metric_transformation {
    name          = "ErrorCount"
    namespace     = "Example/Logs"
    value         = "1"
    default_value = "0"
    unit          = "Count"
  }
}

resource "aws_cloudwatch_metric_alarm" "high_error_count" {
  alarm_name          = "ExampleHighErrorCount"
  comparison_operator = "GreaterThanThreshold"
  evaluation_periods  = 2
  datapoints_to_alarm = 2
  metric_name         = "ErrorCount"
  namespace           = "Example/Logs"
  period              = 300
  statistic           = "Sum"
  threshold           = 100
  treat_missing_data  = "missing"
  alarm_description   = "More than 100 matching error events in each of two 5-minute periods"
  alarm_actions       = [var.alerts_topic_arn]
}

The permission precedes the Lambda subscription and is restricted by log-group ARN and source account. The SNS alarm destination also needs its appropriate topic policy. Function deployment, execution-role policy, topic subscriptions and end-to-end notification are separate prerequisites.

The alarm is an error count, not an error rate: more than 100 matching events in each of two five-minute periods. default_value = 0 applies when logs arrive but none match; no incoming logs can still mean missing data. treat_missing_data = "missing" does not treat silence as health. Metric filters do not backfill historical events, and duplicates can affect counts.

Export Tasks and S3 Lifecycle

For a bounded historical export, use CloudWatch's separate S3 export task API and its bucket/KMS permissions. Export availability can lag by up to 12 hours, ordering is not guaranteed, and the service does not recommend periodic export tasks for continuous archiving.

Archive lifecycle rules belong to the bucket's single configuration owner. Merge a reviewed prefix-scoped rule into that configuration instead of replacing existing rules with a second Terraform resource. Consider small-object transition behavior, minimum storage durations, retrieval costs and Object Lock before selecting Standard-IA or Glacier tiers.

Cost Optimization

Cost Structure

Check current regional/class/tier pricing for ingestion, retained storage, query scans, vended delivery, transformation and downstream services. Firehose, S3, KMS, Lambda, custom metrics and alarms are not universally free. The older table did not substantiate its Seoul rates or a zero-cost “Logs to S3” path.

The following is hypothetical arithmetic, not current regional pricing:

Assumption	Monthly calculation
100GB/day ingested for 30 days at an assumed $0.50/GB	3,000 × $0.50 = $1,500
30-day steady-state retention, assumed stored fraction 0.5, $0.03/GB-month	Average 1,500GB × $0.03 = $45
200GB scanned daily for 30 days at an assumed $0.005/GB	6,000 × $0.005 = $30
Subtotal under only these assumptions	$1,575

This is not the first month's storage ramp, a compression benchmark, or a complete bill. The original $1,576 total mixed daily/monthly query values. Use measured average retained bytes, scan volume, current rates and all other charge categories.

Filtering, Retention and Log Levels

Filter only records that your diagnostic and security requirements allow you to discard. Fluent Bit classic configuration is not YAML. With this record structure, a namespace filter uses a record accessor such as $kubernetes['namespace_name'], not the nonexistent flat field kubernetes_namespace_name.

Avoid broad substring filters that discard useful errors merely because they mention a health-check path. Prefer explicit fields such as a reviewed event type, and verify examples that must be retained as well as dropped.

Different retention periods can be appropriate for development, production and audit needs, but changing retention can delete data. All control-plane streams in one group share the group's policy. Application log levels are an application contract: putting LOG_LEVEL: INFO in a ConfigMap does nothing unless the application consumes and implements it. Temporarily increased verbosity needs access controls, an expiry and a volume budget.

Cost Monitoring

Use AWS/Logs metrics such as IncomingBytes and IncomingLogEvents with the LogGroupName dimension and Sum statistic. They describe ingestion, not the entire invoice. @billedDuration is a Lambda field, not CloudWatch Logs' storage or ingestion billing metric.

aws logs describe-log-groups --region "$DOCS_REGION" \
  --log-group-name-prefix /aws/containerinsights/example-eks/ \
  --query 'logGroups[].{name:logGroupName,retention:retentionInDays,class:logGroupClass,storedBytes:storedBytes}'

# Example complete month; End is exclusive.
aws ce get-dimension-values --region us-east-1 \
  --time-period Start=2026-08-01,End=2026-09-01 \
  --dimension SERVICE --search-string CloudWatch

Use the returned billing-service value in a Cost Explorer filter, and include related services when estimating the complete pipeline. storedBytes is a log-group attribute, not a guaranteed AWS/Logs metric of that name. Querying all logs to estimate their cost can itself incur query charges.

Validation and References

The audit checked local Terraform/Helm configuration, Kubernetes schema, SDK payload types, synthetic Lambda events, bilingual examples, quiz answers and Markdown rendering. These checks do not prove live IAM, collector delivery, managed QL execution, Firehose archives, alarm delivery or actual costs.

• EKS control-plane logs
• CloudWatch Observability add-on and Helm installation
• Auto Mode managed-component log delivery
• Log classes and quotas
• Fluent Bit native CloudWatch output
• QL filter, stats, functions, and SOURCE
• Subscription examples and destination API
• CloudWatch Logs to Firehose limitations, decompression, and message extraction
• Metric filters, S3 export tasks, and CloudWatch Logs service metrics
• SNS Publish API and current CloudWatch pricing

Quiz

Check the distinctions with the CloudWatch Logs Quiz.
